Tier 1 long lifespan LiFePO4 Battery
Smart BMS to protect the battery
LCD display screen monitor
Support parallel connection
Plug & Play
IP21(IP65 optional)
| Model Number | WMA5K | WMA9.6K | WMA10K | |
|---|---|---|---|---|
| Nominal Voltage | 51.2V | 48V | 51.2V | |
| Rated Capacity | 100Ah | 200Ah | 200Ah | |
| Energy | 5120Wh | 9600Wh | 10240Wh | |
| Internal Resistance | ≤30mΩ | ≤30mΩ | ≤30mΩ | |
| Month Self Discharge | <3% | <3% | <3% | |
| Working Voltage Range | 48~56.5V | 43~53V | 48~56.5V | |
| Max.Charging Current | 50.0A | 100.0A | 100.0A | |
| Max.Discharging Current | 100.0A | 100.0A | 100.0A | |
| Communication Protocol | RS485/RS232/CAN | RS485/RS232/CAN | RS485/RS232/CAN | |
| Dimension(mm) (L*W*H) | 580*390*185mm | 485*690*186mm | 485*690*186mm | |
| Cell Type | LiFePO4 3.2V | LiFePO4 3.2V | LiFePO4 3.2V | |
| IP Class | IP21(IP65 optional) | IP21(IP65 optional) | IP21(IP65 optional) | |
| Case Material | Metal Case | Metal Case | Metal Case | |
| Operating Temperature | Charging:-10°C-50°C Discharging: -20°C~50°C Storage:0°C~40°C | Charging:-10°C-50°C Discharging: -20°C~50°C Storage:0°C~40°C | Charging:-10°C-50°C Discharging: -20°C~50°C Storage:0°C~40°C | |
| Cycles | >6000 cycles | >6000 cycles | >6000 cycles |
